PULSAR 6255G 900HP 62mm Dual Ball Bearing Turbo
PULSAR 6255G 900HP 62mm Dual Ball Bearing Turbo
PULSAR 6255G 900HP 62mm Dual Ball Bearing Turbo
PULSAR 6255G 900HP 62mm Dual Ball Bearing Turbo
PULSAR 6255G 900HP 62mm Dual Ball Bearing Turbo

PULSAR 6255G 900HP 62mm Dual Ball Bearing Turbo

by Pulsar Turbos Australia
$999.00 - $2,349.00
$1,369.00
$999.00 - $2,349.00
$1,369.00

Fast Dispatch

Ships in 1–5 business days from our warehouse. Australia-wide delivery available.

Buy with Confidence

Secure checkout and support available if you need help before or after purchase.

  • Dual ceramic ball bearing system provides optimal turbo response &
    better durability by reducing the shaft-motion
  • 9 Blade PTG-Aero billet compressor wheel with extended tapered tip technology
  • 9 Blade PTG-Aero Inconel 713c turbine wheel
  • Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
  • Optional Internal Wastegate (IWG), Billet Actuator (Working pressure 12 psi)
  • Compressor Wheel: 62*76mm
  • Turbine Wheel: 60*55mm
  • Compressor Inlet: 4″ Hose
  • Compressor Outlet: 2″ Hose
  • Turbine Inlet: T3 or T4
  • Turbine Outlet: 3″ V-Band
  • Water Ports: 2-M14 X 1.5
  • Oil Inlet: 7/16-24 UNF with a -4AN Restrictor pre-installed
  • Oil Outlet: Std T3 Oil Drain Flange
  • Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp



Housing Options:

  • .83 T3 V Band Rear
  • .82 T4 V Band Rear
  • 1.01 Dual V Band
  • .72 Dual Band IWG
  • .72 Dual Band
  • .83 Dual V Band
  • .92 DVB IWG
  • .49 DVB IWG
  • .85 Divided T4
  • .82 Stainless Steel Dual V Band

Housing Style:

  • Standard Housing
  • Stainless Steel Wrapped Housing — available at additional cost
  • (Please allow 1-2 weeks for stainless steel wrapped housings if stock isn’t available.)

The Stainless Steel Wrapped Housing option adds an external stainless steel heat-retaining wrap around the turbine housing to help contain radiant heat around the turbine area.

Where listed, the turbocharger can also be selected without a turbine housing.
